Triton Shannon User Manual

Shannon electric shower
9
leaving the base of the screw head protruding
6 mm out from the wall.
Hook the backplate over the bottom screw and
fit the top fixing screw into position.
DO NOT fully tighten the screws at this stage,
as the fixing holes are elongated to allow for
out of square adjustment after the plumbing
connections have been completed.
T00318
Fig.11
T00316
Fig.9
T00317
20 mm
Fig.10

Triton Shannon Specifications

General

Brand	Triton
Model	Shannon
Category	Plumbing Product
Language	English
