Triton T70gsi Plus User Manual

10
The shower cover has been designed with four
“cut out” bottom pipe access points and one
“cut out” top rear - (fig.9) shows the top cut
out position and the bottom “cut out” positions.
• Decide if top or bottom pipe entry is
required.
• Once chosen, carefully remove the
appropriate “cut out” using a junior
hacksaw and file.
Fitting Procedure
7
Continued
SECTION
PLEASE NOTE: NONE of the 'cut outs'
are designed to 'snap out'. ONLY a junior
hacksaw, file or suitable knife should be
used. Damage to the backplate or cover may
invalidate product specifications
and warranty.
Fig.9
Left hand side
top rear of the
backplate
"Cut out" bottom cover
pipe access points
"Cut out" top cover pipe
access point

Triton T70gsi Plus Specifications

General

Start/Stop Button	Yes
Phased Shutdown	Yes
IP Rating	IPX4
Type	Electric Shower
Voltage	240 V
Cable Entry Points	Top, Bottom, Back, Left, Right
Temperature Control	Thermostatic
