Triton T70gsi Plus User Manual

14
8
Continued
SECTION
3. With the cover off the
shower - turn the power
selector to the OFF
position (fig.15).
1. With the cover off the
shower - turn the POWER
selector spindle clockwise
until the flat section is on
the bottom (fig.13).
2. With the cover off the
shower - turn the stabiliser
valve spindle fully clockwise
until resistance is felt
(fig.14).
4. With the cover off
the shower - turn the
temperature control to
the ‘5 o-clock’ position as
shown in (fig.16).
Fig.13
Fig.14
Fig.15
Fig.16
Flat section
to the bottom
Stabiliser
valve

Triton T70gsi Plus Specifications

General

Start/Stop Button	Yes
Phased Shutdown	Yes
IP Rating	IPX4
Type	Electric Shower
Voltage	240 V
Cable Entry Points	Top, Bottom, Back, Left, Right
Temperature Control	Thermostatic
