Triton TGEOS User Manual

10
GB
Problem Possible cause Solution
No function when On/Off Sliding Switch (7) is
operated
No power
Check if Power Indicator (11) is illuminated; check
power supply
Defective On/Off Sliding Switch
Have the On/Off Sliding Switch replaced by an
authorised Triton service centre
Motor suffers from cut-outs, loss of performance
and produces sparks and/or burning smells
Carbon brushes worn
Replace carbon brushes (see ‘Maintenance’), or
have the brushes replaced by an authorised Triton
service centre
No sanding action when On/Off Sliding Switch (7)
is operated, despite the motor running
Mode Selector Switch (3) in between settings;
gears not engaged
Ensure the Mode Selector Switch is turned all
the way, and locked in one of the two possible
positions
Slow material removal
Sanding disc too fine or worn Fit new sanding disc with coarser grit
Tool speed set too low Increase tool speed
Wrong sanding mode selected
Change sanding mode as described in ‘Selecting
sanding mode’
Scratches on workpiece after sanding
Sanding disc too coarse Fit new sanding disc with finer grit
Not enough material removed Continue sanding
Burn marks on workpiece
Sanding disc incompatible with material Fit correct sanding disc
Tool speed set too high Decrease tool speed
Too much pressure exerted on to the sander Use less pressure whilst moving the machine
Wrong sanding mode selected
Change sanding mode as described in ‘Selecting
sanding mode’
Excessive dust emission
Vacuum dust extraction system not connected, or
extraction system not switched on
Check connection of the vacuum hose, and ensure
dust extraction system is switched on
Dust extraction not working; sanding disc not
aligned with dust extraction holes in the Backing
Pad; extraction holes blocked
Realign sanding disc; unblock dust extraction
holes
Troubleshooting
460509_Z1MANPRO1.indd 10 24/04/2015 10:20

Triton TGEOS Specifications

General

Brand	Triton
Model	TGEOS
Category	Sander
Language	English
