Triumph MULTI-SPORT COMBO - Set-up Instructions - Base Assembly; Step 1: Prepare Base; Step 2: Attach Base Bracket; Step 3: Insert Base Poles

-5-
Assembly (Storage is the reverse of assembly)
Set-up Instructions
STEP 1
STEP 2
STEP 3
Press
spring locks
1
7
2
1
2
3
Note: Hold Bracket (#2)
when attaching Tubes (#3)
Adhere six Non-Slip Pads #7 to the
bottom of the Base.
Flip base over and slide Base Bracket #2
into base as shown.
Insert yellow telescoping poles #3 to each
side, by pressing both locks and sliding
the poles into the Base Bracket #2 until
the Spring locks are engaged.
Note: Hold Bracket (#2) when
attaching Tubes (#3)
Note: Having a second person help you
will make this assembly easier.
