Assembly (Storage is the reverse of assembly)
Badminton Game Instructions
To convert from Volleyball
to Badminton: Unhook net
hooks, then press spring
locks and slide telescoping
pole down on both sides
for Badminton net height.
Note: Make sure you
hold the yellow pole
when rotating.
-9-
Note: Having a second person help you
will make this process easier.
Fold down the net and tuck into
the Net Clips shown below.
Now you are ready for
Pickleball!
Base
Base
Pickleball Game Instructions
Note: Having a second person help you
will make this process easier.
DETAIL BDETAIL F
DETAIL BDETAIL E
To convert from Badminton to
Pickleball: Fold down the net
assembly by pressing spring
locks and rotating Pivot
Connector toward the Base
side that has the Net Clips.
See Detail E & Detail F.
Note the location of the Net
Clips on the Base Bracket
as shown in Detail F.
Base
Bracket
To Next Page
