Triumph Street Twin 2019 User Manual

Maintenance and Adjustment
139
• Release the fastener on the Engine
Control Module (ECM) unit.
• Lift the ECM unit and place to the
side allowing access to the battery.
Note
Make sure that the ECM unit is handled
with care during the battery removal or
installation process.
• Remove the battery strap.
• Detach the USB port socket.
• Take the battery out of the case.
Speed Twin, Thruxton and
Thruxton R
3
12
4
1. Battery
2. Positive (+) terminal
3. Negative (-) terminal
4. Battery strap
To remove the battery:
• Remove the seat (see page 72).
• Disconnect the battery leads,
negative (black) lead first.
• Remove the battery strap and the
USB port socket.
• Take the battery out of the case.
Battery Disposal
Should the battery ever require
replacement, the original battery must
be handed to a recycling agent who
will make sure that the dangerous
substances from which the battery
is manufactured do not pollute the
environment.
Battery Maintenance
Warning
Battery acid is corrosive and
poisonous and will cause damage to
unprotected skin.
Never swallow battery acid or allow it
to come into contact with the skin.
To prevent injury, always wear eye
and skin protection when handling the
battery.
The battery is a sealed type and does
not require any maintenance other
than checking the voltage and routine
recharging when required, such as
during storage.
Clean the battery using a clean,
dry cloth. Make sure that the cable
connections are clean.
It is not possible to adjust the battery
acid level in the battery; the sealing
strip must not be removed.

Triumph Street Twin 2019 Specifications

General

Displacement	900 cc
Transmission	5-speed
Frame	Tubular steel cradle
Seat Height	760 mm
Dry Weight	198 kg
Fuel Tank Capacity	12 liters
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Front Tyre	100/90-18
Rear Tyre	150/70 R17
Front Suspension Travel	120 mm
Rear Suspension Travel	120 mm
Rake	25.1°
Wet Weight	216 kg
Standard Warranty	2 years unlimited mileage
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Max Power	65 PS @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Front Suspension	41mm telescopic fork
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Bore x Stroke	84.6 x 80 mm
Exhaust	2-into-2 exhaust system with twin silencers
Clutch	Wet, multi-plate
Swingarm	Twin sided, tubular steel
Front Wheel	18 x 2.5in
Rear Wheel	Cast aluminium alloy multi spoke, 17 x 4.25 in
Instrument Display and Functions	LCD multi-functional instrument pack with analogue speedometer
Length	2090 mm
Wheelbase	1, 415mm
Trail	102.4 mm
