Triumph Street Twin 2019 User Manual

General Information
36
Warning Lights
Engine Management System
Malfunction Indicator Light (MIL)
The Malfunction Indicator
Light (MIL) for the engine
management system
illuminates when the ignition
is switched ON (to indicate that it is
working) but should not become
illuminated when the engine is running.
If the engine is running and there is
a fault with the engine management
system the MIL will be illuminated and
the general warning symbol will flash.
In such circumstances, the engine
management system may switch to
'limp-home' mode so that the journey
may be completed, if the fault is not so
severe that the engine will not run.
Warning
Reduce speed and do not continue to
ride for longer than is necessary with
the MIL illuminated. The fault may
adversely affect engine performance,
exhaust emissions and fuel
consumption.
Reduced engine performance could
cause a dangerous riding condition,
leading to loss of control and an
accident.
Contact an authorized Triumph dealer
as soon as possible to have the fault
checked and rectified.
Note
If the MIL flashes when the ignition
is switched ON contact an authorized
Triumph dealer as soon as possible to
have the situation rectified. In these
circumstances the engine will not start.
Low Oil Pressure Warning Light
With the engine running, if
the engine oil pressure
becomes dangerously low, the
low oil pressure warning light
will illuminate.
Caution
Stop the engine immediately if the low
oil pressure warning light illuminates.
Do not restart the engine until the
fault has been rectified.
Severe engine damage will result from
running the engine when the low oil
pressure warning light is illuminated.
Note
The low oil pressure warning light will
illuminate if the ignition is switched ON
without running the engine.
High Coolant Temperature Warning
Light
With the engine running, if
the engine coolant
temperature becomes
dangerously high, the high
coolant temperature warning light will
illuminate.

Triumph Street Twin 2019 Specifications

General

Displacement	900 cc
Transmission	5-speed
Frame	Tubular steel cradle
Seat Height	760 mm
Dry Weight	198 kg
Fuel Tank Capacity	12 liters
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Front Tyre	100/90-18
Rear Tyre	150/70 R17
Front Suspension Travel	120 mm
Rear Suspension Travel	120 mm
Rake	25.1°
Wet Weight	216 kg
Standard Warranty	2 years unlimited mileage
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Max Power	65 PS @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Front Suspension	41mm telescopic fork
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Bore x Stroke	84.6 x 80 mm
Exhaust	2-into-2 exhaust system with twin silencers
Clutch	Wet, multi-plate
Swingarm	Twin sided, tubular steel
Front Wheel	18 x 2.5in
Rear Wheel	Cast aluminium alloy multi spoke, 17 x 4.25 in
Instrument Display and Functions	LCD multi-functional instrument pack with analogue speedometer
Length	2090 mm
Wheelbase	1, 415mm
Trail	102.4 mm
