Triumph Street Twin 2019 User Manual

General Information
53
System Display
Warning
Do not attempt to switch between
front and rear tire display modes with
the motorcycle in motion as this may
lead to loss of motorcycle control and
an accident.
10
20
1
10
1
20
1
20
0
0
20
40
60
1
80
200
1
2
3
4
1. TPMS warning light
2. TPMS symbol
3. Tire pressure
4. Front and rear tire indicators
To view the tire pressure display:
• Make sure the motorcycle is
stationary and in neutral. Turn the
ignition to the ON position.
• Press and release the SCROLL
button until PSI or bAr is shown in
the display screen.
• Press and hold the SCROLL button
for one second to change between
PSI and bar.
• Once PSI or bar has been selected,
press and release the SCROLL
button to select the front or rear
tire pressure.
• When the tire pressure monitoring
system has been selected, —— PSI
or bAr is shown in display screen
until the motorcycle is traveling at a
speed greater than 12 mph (20 km/h)
and the tire pressure signal is
received.
• To exit the tire pressure display,
press and release the SCROLL
button until the desired display
screen is shown.
Sensor Batteries
When the battery voltage in a pressure
sensor is low, LO bAt will be displayed
and the TPMS symbol will indicate
which wheel sensor has the low battery
voltage. If the batteries are completely
flat, only dashes will be visible in the
display screen, the red TPMS warning
light will be on and the TPMS symbol
will flash continuously. Contact your
authorized Triumph dealer to have the
sensor replaced and the new serial
number recorded in the spaces provided
on page 52.
With the ignition switch turned to the
ON position, if the TPMS symbol flashes
for 10 seconds and then remains on
there is a fault with the TPMS system.
Contact your authorized Triumph dealer
to have the fault rectified.

Triumph Street Twin 2019 Specifications

General

Displacement	900 cc
Transmission	5-speed
Frame	Tubular steel cradle
Seat Height	760 mm
Dry Weight	198 kg
Fuel Tank Capacity	12 liters
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Front Tyre	100/90-18
Rear Tyre	150/70 R17
Front Suspension Travel	120 mm
Rear Suspension Travel	120 mm
Rake	25.1°
Wet Weight	216 kg
Standard Warranty	2 years unlimited mileage
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Max Power	65 PS @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Front Suspension	41mm telescopic fork
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Bore x Stroke	84.6 x 80 mm
Exhaust	2-into-2 exhaust system with twin silencers
Clutch	Wet, multi-plate
Swingarm	Twin sided, tubular steel
Front Wheel	18 x 2.5in
Rear Wheel	Cast aluminium alloy multi spoke, 17 x 4.25 in
Instrument Display and Functions	LCD multi-functional instrument pack with analogue speedometer
Length	2090 mm
Wheelbase	1, 415mm
Trail	102.4 mm
