Triumph Street Twin 2019 User Manual

General Information
72
• Place the seat cover facing
upwards, on a clean, flat surface
using the metal stand and two
plastic stands at the rear of the
seat to rest on.
• See page 154 for seat cleaning
information.
Seat Lock
Warning
To prevent detachment of the seat
during riding, after installation always
grasp the seat and pull firmly upwards.
If the seat is not correctly secured in
the lock, it will detach from the lock.
A loose or detached seat could cause
loss of motorcycle control and an
accident.
1
1. Seat lock
The seat lock is located on the left hand
side of the motorcycle, on the frame
below the seat.
The seat can be removed to gain access
to the battery, fuse box (on certain
models) and Owner's Handbook.
Seat Removal and Installation
Warning
To prevent detachment of a seat
during riding, after installation always
grasp the seat and pull firmly upwards.
If the seat is not correctly secured it
will detach from the lock.
A loose or detached seat could cause
loss of motorcycle control and an
accident.
All Models except Street Scrambler
Seat Removal
To remove the seat:
• Insert the ignition key into the seat
lock and turn it counterclockwise.
This will release the seat from its
lock.
• Slide the seat upwards and
rearwards for complete removal
from the motorcycle.
Seat Installation
To reinstall the seat:
• Engage the seat's tongue
underneath the bracket near the
fuel tank.
• Line up the hinges and press down
at the rear to engage the seat lock.
Note
An audible click can be heard when the
seat is fully engaged into its lock.

Triumph Street Twin 2019 Specifications

General

Displacement	900 cc
Transmission	5-speed
Frame	Tubular steel cradle
Seat Height	760 mm
Dry Weight	198 kg
Fuel Tank Capacity	12 liters
Compression Ratio	11.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Front Tyre	100/90-18
Rear Tyre	150/70 R17
Front Suspension Travel	120 mm
Rear Suspension Travel	120 mm
Rake	25.1°
Wet Weight	216 kg
Standard Warranty	2 years unlimited mileage
Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel twin
Max Power	65 PS @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Front Suspension	41mm telescopic fork
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Bore x Stroke	84.6 x 80 mm
Exhaust	2-into-2 exhaust system with twin silencers
Clutch	Wet, multi-plate
Swingarm	Twin sided, tubular steel
Front Wheel	18 x 2.5in
Rear Wheel	Cast aluminium alloy multi spoke, 17 x 4.25 in
Instrument Display and Functions	LCD multi-functional instrument pack with analogue speedometer
Length	2090 mm
Wheelbase	1, 415mm
Trail	102.4 mm
