Parts Identification
10
11
5
9
7
T509-28b
1.
indicator
8.
Side Stand
2.
Headlamp
9.
Gearchange Pedal
3.
Position Lamp
10.
Front Brake Disc
4.
Rear Lamp
11.
Front Brake Caliper
5.
Radiator
12. Fuel Tank
6. Oil Cooler
13.
Fuel Filler Cap
7.
Drive Chain
14.
Seat Lock
