PARTS IDENTIFICATION
26
Rider View Parts Identification
Bonneville T100 (all models), Bonneville T120 (all models), Speed Twin 1200 and
Thruxton RS
2
1
3
4
5
6
78
9
15
10
11
1213
1617
14
1. Clutch lever
2. Headlight dimmer switch
3. SCROLL button
4. Daytime Running Lights (DRL) switch
(if equipped)
5. Speedometer
6. Warning lights
7. Trip computer/Odometer/Information
display screen
8. Tachometer
9. Information display screen
10. Front brake fluid reservoir
11. Front brake lever
12. Engine start/stop switch
13. MODE button (Bonneville T120 (all models)
only)
14. Hazard button
15. MODE button (Speed Twin 1200 and
Thruxton RS only)
16. Horn button
17. Turn signal switch
