PARTS IDENTIFICATION
27
Rider View Parts Identification
Scrambler 900 and Speed Twin 900
(Speed Twin 900 shown)
1
3
45 6
78
91 0
11
2
14 1213
1. Clutch lever
2. Headlight dimmer switch
3. SCROLL button
4. Speedometer
5. Warning lights
6. Odometer/Information display screen
7. Front brake fluid reservoir
8. Front brake lever
9. Engine start/stop switch
10. Hazard button
11. MODE button
12. Daytime Running Lights (DRL) switch
(if equipped)
13. Horn button
14. Turn signal switch
