16. SPECIFICATIONS
Satellite specification
System standard Fully MPEG2/DVB Compliant
Channel Storage Max.4000 TV and Radio Channels totally
Input Frequency 950~2150MHz
LNB Control DiSEqC1.0/1.2, USALS
LNB Power 13V/18V (Max, 400mA)
LNB tone switch 22KHZ
Symbol rate 2~45Mbps
A/V Mode
Video format MPEG-2 Main profile/Main level
Audioformat MPEG-1layer &
Aspect Ratio 16:9, 4:3
Audio sampling rate 32, 44.1, 48 kHz
Audio type Left channel, Right channel, Stereo
Graphic display 720x576(PAL), 720x480(NTSC)
Microprocessor & Memories
Processor CT216S-Z
SDRAM 16 Mbits
FLASH 2 Mbits
Power & Environment condition
Supply voltage 90~250V AC, 50/60Hz
Supply power Max.10W
Operational temperature 5 C~60 C
Physical specification
LED display red & green
Weight 0.65 kg
Dimensions 196(W) x 126(D) x 42(H) mm
Connections
Satellite IF input F-type (Digital)
Satellite IF loop out F-type (Digital)
USB Port USB 2.0
Video CVBS
Audio RCA Audio left, Audio right
Control Output 0/12V out
RS-232 Female Connector
Specification is subject to change without notice.
8.30
P
LAY NEX T RECORDED FI L E ............................................................................................................ 16
8.31
T
IMESHIFT ....................................................................................................................................... 16
9. MENU .............................................................................................................................. 16
9.1 GENERAL MENU MA NAGED ROLES .................................................................................................... 17
10. CHANNEL LIST............................................................................................................. 17
10.1 TV LIST,RADIO LIST....................................................................................................................... 17
10.2 F
AVORITEMANAGER ...................................................................................................................... 19
11. INSTALLATION............................................................................................................. 19
11.1 SATELLITE SETTING ........................................................................................................................ 19
11.2 S
EARCH CHA NNEL S ......................................................................................................................... 20
11.3 TP M
ANAGER .................................................................................................................................. 22
12. MULTIMEDIA.................................................................................................................22
12.1 MY ALBUM...................................................................................................................................... 23
12.2 M
Y MUSIC ....................................................................................................................................... 23
12.3 M
Y MOV I E....................................................................................................................................... 23
12.4 M
Y RECORDI NGS............................................................................................................................. 24
13. UTILITY.......................................................................................................................... 25
14. SETUP ........................................................................................................................... 25
14.1 GENERA L SETTING .......................................................................................................................... 25
14.2 TV S
ETUP ........................................................................................................................................ 26
14.3 P
A SSWORD ....................................................................................................................................... 26
14.4 A
DVANCE TIMER ............................................................................................................................. 27
14.5 SW U
PD AT E..................................................................................................................................... 27
14.6 S
ET DEFA UL T .................................................................................................................................. 28
15. TROUBLE SHOOTING.................................................................................................. 29
16. SPECIFICATIONS ......................................................................................................... 30
17. DECLARATION OF CONFORMITY .............................................................................. 31
