Trojan MARATHON 220 - Page 8

8
PARTS LIST
No. Description Qty
56 Nylon Washer (Ø10 x Ø25 x 3T) 1
57 Sensor W/Cable (1000 mm) 1
58 Sensor Rack 1
59 Square End Cap (Ø1” × 1”) 1
60 Square End Cap (Ø21.4 × 21.4 mm) 1
61 Hex Head Bolt (1/2” x 98 mm) 2
62 Hex Head Screw (3/8” x 3/4”) 4
63 Hex Head Screw (3/8” × 1-3/4”) 1
64 Hex Head Screw (3/8” × 1-1/2”) 1
65 Hex Head Screw (M8 × 60 mm) 1
66 Hex Head Screw (3/8” x 2-1/2”) 1
68 Button Head Socket Screw (5/16” x 1-1/4”) 2
69 Button Head Socket Screw (5/16” x 1-3/4”) 2
70 Socket Head Cap Screw (1/4” x 60 mm) 2
71 Flat Head Socket Screw (M6 x 20 mm) 6
72 Phillips Head Screw (M5 × 10 mm) 2
73 Split Washer (3/8” x 2T) 4
74 Nyloc Nut (M8 × 8T) 1
75 T Nyloc Nut (1/2” x 8T) 2
76 Nyloc Nut (5/16” x 7T) 2
77 Nyloc Nut (3/8” x 7T) 2
78 Flat Washer (3/8” x 7T) 5
79 Flat Washer (5/16” x 18 x 1.5T) 10
80 Flat Washer (1/2” x 26 x 2T) 2
81 Flat Washer (3/8” x 19 x 1.5T) 2
82 Flat Washer (5/16” x 35 x 1.5T) 2
83 Trapping Screw (5 x 25 mm) 4
84 Tapping Screw (5 x 16 mm) 5
85 Tapping Screw (5 x 16 mm) 18
No. Description Qty
86 Split Washer (M5) 2
87 Sheet Metal Screw (4 x 12 mm) 4
88 Star Washer (5 mm) 2
89 Sheet Metal Screw (4 x 50 mm) 2
90 Hex Head Bolt (M8 x 12 mm) 2
91 Split Washer (M8 x 1.5T) 2
92 Nylon Cap (Ø8.5 × Ø36) 2
93 Tapping Screw (5 x 19 mm) 8
94 Button Head Socket Bolt (5/16” × 1/2”) 10
95 Curved Washer (5/16” x 23 x 1.5T) 2
97 Allen Wrench (M5/M6) 2
98
Combination (M5) Allen Key & Phillips Screw
Driver
1
99 Lubricant 1
100 Rear Roller Cover 2
101 Tapping Screw (3.5 x 16 mm) 6
102 Wire Tie Mount 6
103 Handgrip End Cap 2
105 Flat Head Socket Screw (M6 x 25 mm) 2
106 Handpulse Wire (Upper) (550 mm) 2
113 Non-Slip Rubber (L) 1
114 Non-Slip Rubber (R) 1
115 Filter 1
116 Choke 1
117 Connecting Cable Of Motor (400 mm) 1
118 Connecting Wire (White) (250 mm) 1
119 Bolt Cap (13 mm) 2
120 Bolt Cap (14 mm) 2
121 Tapping Screw (5 x 12 mm) 6
