PARTS LIST
No. Description Qty
1 Main Frame 1
2 Frame Base 1
3 Left Upright 1
4 Right Upright 1
5 Console Support 1
6 Outer Slide 1
7 Inner Slide 1
8 Inclination Adjustor Bar 1
9 Wheel Sleeve 2
10 Locking Knob 1
11 Belt Guide 2
12 Motor Bracket 1
13 Motor 1
14 Drive Belt 1
15 Running Deck 1
16 Running Belt 1
17 Front Roller W/Pulley 1
17-1 Magnet 1
18 Rear Roller 1
19 Frame Cover 1
20 Console Assembly 1
20-1 Top Console Cover 1
20-2 Inner Console Cover 1
20-3 Square Magnet Stop Plate 2
20-4 Safety Switch Module W/ Cable (300 mm) 1
20-8 Self Tapping Screw (3 × 10 mm) 2
20-9 Self Tapping Screw (3.5 x 12 mm) 6
21 Top Motor Cover 1
24 Inclination Adjustor Bushing 2
No. Description Qty
25 Rear Adjustment Base (L) 1
26 Rear Adjustment Base (R) 1
27 Motor Cover Anchor 4
28 Transportation Wheel 2
29 Wheel Cover 2
30 Rubber Foot Pad 2
31 Foot Rail 2
32 Rubber Foot 6
33 Square End Cap (Ø25 x 50) 2
34 Rubber Foot Pad 2
35 Isolator 2
36 Inclination Adjustor (L) 1
37 Inclination Adjustor (R) 1
38 Wire Protective Rubber 1
41 Grommet 1
42 Console Cable (Lower) (600 mm) 1
43 Handgrip Foam 2
44 Ellipse Safety Key (800 mm) 1
45 Console Cable (Upper) (800 mm) 1
46 Console Cable (Middle) (1100 mm) 1
47
Connecting Wire (Black) (100 mm x 764 x
764)
1
48
Connecting Wire (White) (150 mm x 764 x
764)
1
49 Connecting Wire (Black) (150 mm x 764 x 764) 1
50 Motor Controller 1
51 Breaker 1
52 On/Off Switch 1
53 Power Cord 1
54 Hand Pulse Assembly 2
55 Hand Pulse Wire (Lower) (400 mm) 2
