Trophy TA-1001HD - TV Set Connections; RCA Input Connection; SCART Input Connection

DC 12VUSBHDMISPDIFPbYPr
LOOPRF IN
AUDIO-R AUDIO-L CVB-S
DC 12VUSBHDMISPDIFPbYPr
LOOPRF IN
AUDIO-R AUDIO-L CVB-S
7
www.trophy.com.ua
Trophy TA-1001HD User Manual
Connection of Device to TV Set
with RCA Input
Connection of Device to TV Set
with SCART Input
RCA
CVBS
General
Cb
General
Y
General
Cr
General
SCART
(20) VIDEO
(17) General
(7) BLUE
(5) General
(11) GREEN
(9) General
(15) RED
(13) General
Sat LNB output
Sat LNB output
