Trotec BX09 User Manual

4 EN
energy cost measuring device BX09
Information about the device
Device description
The device BX09 measures the energy demand of a connected
terminal device.
The consumption of the device can be displayed in watts, kWh,
the price or costs per kWh.
The device BX09 is available in different versions for connection
to mains sockets in the EU(BX09 EU), Switzerland(BX09 CH),
the United Kingdom(BX09 UK) and France(BX09 FR). The
images in these instructions show the BX09EU by way of
example.
Device depiction
BX09 EU
1
2
3
4
5
6
BX09 CH
BX09 FR
BX09 UK
No. Designation
1 Socket connection
2 Connection for the terminal device (plug adapter)
3 UPbutton
4 MODEbutton
5 SETbutton
6 Display
