6 EN
energy cost measuring device BX09
2. Plug the device into a properly fused socket.
3. Connect the terminal device to the plug adapter.
ð The device is switched on.
Setting the price per kilowatt hour
Note
The default setting ex factory of the price per kilowatt
hour is 0.0.
1. Press the MODE button(4) several times until COST/
KWH(10) appears on the display(6).
ð The currently set price per kilowatt hour is indicated on
the display(6).
2. Press the SET button(5).
ð The first digit in the measurement value display(7)
flashes.
3. Repeatedly press the UP button(3) to set the desired value.
4. Then press the SET button(5) again.
ð The second digit in the measurement value display(7)
flashes.
5. Repeatedly press the UP button(3) to set the desired value.
6. Continue until all four digits have been set.
7. Then press the SET button(5) again.
ð The decimal point in the measurement value display(7)
flashes.
ð If required, you can change the position of the decimal
point by use of the UP button(3).
8. Press the SET button(5).
ð The price per kilowatt hour is set and indicated on the
display(6).
Changing the display mode
The device can display the following values:
• the overall costs (PRICE)
• the price per kilowatt hour (COST/KWH)
• the consumption in real time (W)
• the overall consumption since switch-on (KWH)
1. Press the MODE button(4) until the desired display mode
is set.
Reset
Please proceed as follows to reset the display for the measured
kilowatt hours to 0.00:
1. Repeatedly press the MODE button(4) until the device is in
the display mode for overall consumption since switch-on
(KWH display, 10).
2. Press and hold the MODE button(4) for approx. 3s.
ð The overall consumption since switch-on is reset to
0.00.
Internal memory
The device comes with an internal memory. The price per
kilowatt hour and the overall costs are saved, even if the device
is not connected to the mains.
Shutdown
1. Disconnect the terminal device from the plug adapter.
2. Disconnect the device from the mains.
3. Store the device according to the Storage chapter.
Maintenance and repair
Cleaning
Clean the device with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Do not use any
sprays, solvents, alcohol-based cleaning agents or abrasive
cleaners, but only clean water to moisten the cloth.
Repair
Do not modify the device or install any spare parts. For repairs
or device testing, contact the manufacturer.
Errors and faults
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
For repairs or device testing, contact the manufacturer.
Fault Remedy
The device display indicates
unusual characters or values.
Disconnect the device from the
mains and reconnect it after a
brief period of time. Check
whether the fault is eliminated.
Please contact the Trotec
customer service if the
problem persists.
The device does not respond to
the push of a button.
