EN 24
Operating manual – local air conditioner PAC 2010 E / PAC 2610 E
No. Spare part No. Spare part No. Spare part
1 Top Cover Assy 26 Compressor and Fittings 51 Condenser Assy
2 Membrane 27 Compressor Gasket 52 Diversion Circle
3 Coping 28 Water Retaining Box 53 Motor Holder
4 fixed support (top cover) 29 Chassis Assy 54 Foam (Water Tray)
5 Display Board 30 Motor Sub-assy(Flutter) 55 Centrifugal Fan
6 Display Board 31 Splash Water Flywheel 56 Evaporator Assy
7 Cover of Propeller Housing 32 Fan Motor 57 Fan Motor
8 Air Flue Assy 33 Castor 58 Filter Sub-assy 2
9 Propeller Housing(Upper) 34 Chassis Sub-assy 59 Left Side Plate
10 Centrifugal Fan 35 Water Level Switch 60 Electric Box Assy
11 Propeller Housing(Lower) 36 water Level Switch Base 61 Electric Box Sub-Assy
12 Filter Sub-assy 1 37 Water Level Switch Sub-assy 62 fixed support (mainboard)
13 Front Grill 38 Discharge Tube Sub-assy 63 Main Board
14 Rear Plate 39 Inhalation Tube Sub-assy 64 Capacitor CBB61S
15 Supporting Board 3 40 Capillary Sub-assy 65 Temperature Sensor
16 Wire Clamp 41 Front Panel Assy 66 Temperature Sensor
17 Cover of drainage hole 42 Front Panel 67 Tube sensor
18 Rubber Plug 43 Decorative Strip 68 Electric Box Cover
19 Cable Cross Plate 44 Air Louver 3 69 Rear Grill
20 Capacitor Box Sub-Assy 45 Air Louver 2 70 Power Cord
21 Capacitor Box Assy 46 Air Louver 1 71 Rear Clip (lower)
22 Capacitor Box 47 Swing Lever 72 Rear Clip (upper)
23 Capacitor CBB65 48 Guide Louver 2 73 Pipe
24 Right Side Plate 49 Guide Louver 1 74 Joint
25 Supporting Board 1 50 Guide Blade Lever
