EN 18
Operating manual – local air conditioner PAC 3500 E
No. Spare part No. Spare part No. Spare part
1 Universal wheel 22 The suction pipe 43 Evaporator
2 Base pan 23 Delivery tube 44 Induction temperature head bracket
3 Floator 24 Sensor 45 The rear panel
4 Floater button 25 The front panel 46 Wrapping post
5 Water level switch 26 Blower motor 47 EVA filter
6 Switch stator 27 The motor bracket 48 EVA filter frame
7 The support frame 28 Before the upper air duct 49 CON filter
8 Electrical box base 29 Blowing wind wheel 50 The drain cover
9 Isolated column 30 After the upper air duct 51 The drain cover
10 Main control electric board 31 The positioning ring 52 Power cord
11 Compressor Capacitor 32 Stepper motor cover 53 lower air duct
12 Up fan capacitor 33 Stepper motor 54 Water wheel
13 Down fan capacitor 34 Rocker 55 Water motor bracket
14 Capacitance card 35 Cover 56 Water motor
15 The electric box cover 36 Facial mask 57 Safety net
16 Compressor mat 37 The connecting rod 58 The air exhaust wind wheel
17 Claw type gasket 38 The wind guide bar 59 lower air duct
18 Nut 39 The wind guide bar 60 Exhaust fan motor
19 Compressor 40 Display panel 61 Condenser
20 The four pass filter 41 Remote control
21 Capillary 42 Baffle
Disposal
In the European Union, electronic equipment must not be
treated as domestic waste, but must be disposed of
professionally in accordance with Directive 2002/96/EC of the
European Parliament and of the Council of 27January 2003 on
waste electrical and electronic equipment (WEEE). At the end of
its life, please dispose of this device according to the valid legal
requirements.
The device uses an environmentally and ozone-neutral cooling
agent (see Technical Data).
Dispose of the refrigerant appropriately and according to the
national regulations.
