Trotec PAE 49 - Filling the Water Tank; Water Tank Filling Procedure

EN 9
air cooler PAE 49 / PAE 50
Filling the water tank
The device requires fresh drinking water for air cooling.
Note
Fill the device with fresh drinking water only. The
water temperature must not exceed 40°C.
Info
If possible, change the water every3days to prevent
bacterial growth.
Observe the following when using the ice packs:
• Put the ice packs into a freezer for at least 4hours before
use.
• Put the ice packs into the water tank before filling water
into the tank.
Info
When using ice packs at high outside temperatures,
condensation may form at the water tank and drip onto
the floor.
1. Disconnect the device from the mains before refilling water
or putting ice packs into the device.
2. Open the water funnel(3).
3. Ensure tight fit of the rubber stopper(10), for otherwise
there might be uncontrollable water leakage.
4. Fill the water tank(11) with fresh drinking water only.
Optionally, you can add ice cubes made of drinking water
for additional cooling.
ð Observe the minimum and maximum filling level at the
filling level indicator.
The water tank must be filled up to minimum filling level
to enable pump operation.
5. If required, put the ice packs into the water tank(11) for
additional cooling. The ice packs can be inserted in two
ways.
ð Option1: Insert the ice packs into the device through
the water funnel.
ð Option2: Remove the evaporation filter(5) and the air
filter(9) at the rear of the device and insert the ice
packs.
6. Close the flap of the water funnel(3) or reinsert the
evaporation filter(5) and the air filter(9).
7. Make sure that the device is neither damp nor wet on the
outside. Otherwise wipe it dry.
