5 EN
Operating manual – air cooler PAE 51
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
To make the device easier to transport, it is fitted with wheels.
Before transporting the device, observe the following:
Switch the device off.
Hold onto the mains plug while pulling the power cable out
of the mains socket.
Empty the water tank.
Do not use the power cable to drag the device.
Release the brakes at the castors.
Only wheel the device on a level and smooth surface.
After transporting the device, observe the following:
Set up the device in an upright position after transport.
Storage
Before storing the device, observe the following:
Empty and clean the water tank prior to storage (see
chapter Maintenance).
Allow the honeycomb filter to dry prior to storage.
Otherwise the device may distribute a musty smell after
restart.
When the device is not being used, observe the following
storage conditions:
dry and protected from frost and heat
in an upright position where it is protected from dust and
direct sunlight
with a cover to protect it from invasive dust if necessary
Place no further devices or objects on top of the device to
prevent it from being damaged.
Remove batteries from the remote control.
Assembly and start-up
Scope of delivery
1x Device
1 x Remote control
1 x Battery for the remote control
1x Honeycomb filter
1x Air filter
1 x Ice pack
1x Manual
Unpacking the device
1. Open the cardboard box and take the device out.
2. Completely remove the packaging.
3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.
Start-up
When positioning the device, observe the minimum distance
from walls or other objects as described in the Technical data
chapter.
A
B
C
C
D
Before restarting the device, check the condition of the
power cable. If there are doubts as to the sound condition,
contact the customer service.
Set the device up in an upright and stable position.
Do not create tripping hazards when laying the power
cable or other electric cables, especially when positioning
the device in the middle of the room. Use cable bridges.

Other manuals for Trotec PAE 51

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Trotec PAE 51 and is the answer not in the manual?

Trotec PAE 51 Specifications

General IconGeneral
TypePortable evaporative air cooler
Control typeTouch
Product colorBlack, White
Handles quantity1
Number of wheels4 wheel(s)
Carrying handle(s)Yes
Airflow663 m³/h
Air speed7 m/s
Noise level60 dB
Number of speeds4
Water tank capacity20 L
Timer duration (maximum)15 h
Suitable for room area up to60 m²
AC input voltage220 - 240 V
Power source typeAC
AC input frequency50 Hz
Package depth390 mm
Package width342 mm
Package height897 mm
Package weight8000 g
Air purifiers functionsCooling, Fan
