Operating manual – Electric heater TEH 20 T / 30 T
9 EN
OUR REF.
PARTS QTY.
A1
CHSERV73
Baseplate 1
A2
CHSERV74
Air Flow Tunnel 1
A3 MP146 Yellow (RAL1021) Painted Side panel 2
A4 MP147 Black Painted Hood (Ø150mm Hose Connection) 1
A5 MP148 Black Painted Command baseplate + Control Panel 1
A6
CHSERV75
Room Thermostat Support 1
A7
CHSERV76
Air Outlet Protection Shield 1
A8 FM017 Ø230 Aluminium Fan Blade 1
A9
CHSERV77
Motor Fan Brackets 3
A10
CHSERV78
Bulb Thermostat Protection 1
B1 PL155 ABS Grip + Back Cover 1
B2 EL282 Cable Gland PG16 1
B3 PL147 Room Thermostat Knob 1
B4 AC589 Rubber Feet 4
EL295 3.3kW Heating Element (TEH30T) 1
EL299 2.5kW Heating Element (TEH20T) 1
C2 EL278 230V ~50Hz; 12W Motor Fan 1
C3 EL303 60°C Bi-Metallic Thermostat - 20A 1
C4 EL285 Terminal Block 1
C5 EL305 1.5µF Starting Capacitor 1
CA54 2,75m. H07RNF3G2,5 Supply Cable With Injected Schuko Plug (TEH30T
)1
CA57 2,75m. H07RNF3G1,5 Supply Cable + Fused UK Plug (TEH20T
)1
C7 EL307 I/0 Switch (Green Fluor) 1
C8 EL302 Heating Element Lamp (Red) 1
C9 EL286 TY95 Room Thermostat 1
n/a Housing - M4 x 10 Screws; Black Passivated; ISO 7380 6
n/a PA343 Housing - M5 Safety Nuts; Zinc plated; DIN 982 8
n/a PA214 Housing - M5 Washers; Zinc plated; DIN 9021 8
n/a PA334 Handle - M4 x 16; Black Passivated; DIN 7500 8
n/a Feet - M4 Safety Nuts; Zinc plated; DIN 982 4
n/a AC222 General - Ø4 x 8 Aluminium Blind Rivet; 27
C6
ASSEMBLIES
TEH20T / TEH30T
POS.
PLASTICS
C1
ELECTRIC COMPONENTS METALLIC PARTS
