Operating manual – Electric heater TEH 20 T / 30 T
7 EN
17. Appendix: Circuit diagram
2 30V /50Hz
M
E
Ph
N
S1
S2
S3
M
HE
L
E
Ph
N
Shucko Plug
Schukostecker
Electric Diagram
TEH 20 T / 30 T
0/1
E
1
C
2
S2
S1
L
+°C
- Earthing/Erdung
- Electric Phase / Electric Phase
- Common Line/Gemeinsame
On-Oswitch/Geräteschalter 0/1
Fan motor/Lüftermotor
Red lamp (Heating Element ON) /
Signalleuchte“rot “ (Heizelementes AUF)
-
- Room Thermostat/Raumtemperaturregler
- Bimetallic Thermostat / BimetallThermostat
-
- Heating Element/Heizelementes
-
S3
HE
P 3.3 kW
TEH 30 T
TEH 20 T
=
P = 2.5 kW
