EN 19
dehumidifier TTK 120 E / TTK 122 E
Overview of spare parts
Note: The position numbers of the spare parts differ from those
describing the positions of other parts mentioned in this
operating manual.
No. Spare part No. Spare part No. Spare part
1 Control Mask 15 Condenser 30 pin
2 Control Panel 15 Condenser 31 Float
3 Display PCB 16 Evaporator 32 Water tank rubber ring
4 control Box 17 Activated carbon filter 33 Waterproof rubber ring through coil
5 Humidity Sensor 18 Dust proof filter screen 34 Water Tank
6 Handle 20 Power PCB 35 Power Cord
7 Shell 21 Motor Capacitor 37 Tube Temp. Sensor
8 Up Grille 22 Isolate Plate 38 Capillary
9 Grille net 25 Compressor Capacitor 39 down grille
10 Fan blade 26 Magnetic Switch 40 Solenoid valve assembly
11 Motor 28 Base 42 Compressor
13 Condenser 29 Casters
