Trotec TTK 120 E - Technical Specifications; Technical Data for TTK Models

EN 17
dehumidifier TTK 120 E / TTK 122 E
Technical annex
Technical data
Parameter Value
Model TTK120E TTK122E
Dehumidification performance, max. 30 l / 24 h 40 l / 24 h
Air flow rate 240 m³/h 240 m³/h
Operating range (temperature) 5 °C – 35 °C 5 °C – 35 °C
Operating range (relative humidity) 30%– 90%RH 30%– 90%RH
Pressure suction side 1.2MPa 1.2MPa
Pressure outlet side 2.6MPa 2.6MPa
Max. permissible pressure 3.2MPa 3.2MPa
Mains connection 220 V– 240 V / 50 Hz 220 V– 240 V / 50 Hz
Power consumption, max. 0.62 kW 0.75 kW
Nominal current 2.5A 2.5A
Recommended fusing 10A 10A
Refrigerant R290 R290
Amount of refrigerant 83g 96g
GWP factor 3 3
CO
2
equivalent 0.000249t 0.000288t
Water tank 8l 8l
Sound pressure level 52 dB(A) 52 dB(A)
Dimensions (lengthx widthx height) 310 x 453 x 635 mm 310 x 453 x 635 mm
Minimum distance to walls or other objects
top (A):
rear (B):
sides (C):
front (D):
50 cm
50 cm
50 cm
50 cm
50 cm
50 cm
50 cm
50 cm
Weight
25 k
g
27 k
g
