Trotec TTK 75 E - Activities required after maintenance

EN 15
dehumidifier TTK 75 E
4. Refit the condensation tank into the device.
Make sure not to damage the float when inserting or
removing the condensation tank.
In doing so, make sure that the float is positioned
correctly.
In doing so, make sure that the condensation tank is
inserted correctly, for otherwise the device cannot be
switched back on.
Activities required after maintenance
If you want to continue using the device:
• Reconnect the device to the mains.
If you do not intend to use the device for a considerable time:
• Store the device according to the Transport and storage
chapter.
Technical annex
Technical data
Parameter Value
Model TTK75E
Max. dehumidification
performance
20l/ 24h
Air flow rate 150m
3
/h max.
Operating range (temperature) 5 °C to 32 °C
Operating range (relative
humidity)
30% to 90%RH
Pressure suction side 1.2MPa
Pressure outlet side 2.4MPa
Max. permissible pressure 2.6MPa
Mains supply 220 – 240V ~ 50Hz
Max. power consumption 420W
Nominal current 1.8A
Fusing
T1 A/250 V
Type of protection IPX0
Refrigerant R290
Amount of refrigerant 86g
GWP factor 3
CO
2
equivalent 0.000258t
Water tank 3 l
Sound pressure level 43 dB(A)
Dimensions (lengthx widthx
height)
245x 340x 570mm
Minimum distance to walls and
other objects
A: top
B: rear
C: side
D: front
45 cm
45 cm
45 cm
45 cm
Weight 12.5kg
