Trotec TTK 96 E - Technical Specifications; Technical Data of TTK 96 E; TTK 127 E

18 EN
dehumidifier TTK 96 E / TTK 127 E
Technical annex
Technical data
Parameter Value
Model TTK96E TTK127E
Dehumidification performance, max. 30l / 24h 50l / 24h
Dehumidification performance
at 30°C and 80%RH
28.3l/ 24h 46.8 l / 24 h
Air flow rate
level1:
level2:
166 m³/h
191 m³/h
319 m³/h
353 m³/h
Operating range (temperature) 5°C – 32°C 5°C – 32°C
Operating range (relative humidity) 35 %– 100 %RH 35 %– 100 %RH
Pressure suction side 1.0MPa 1.0MPa
Pressure outlet side 2.6MPa 2.6MPa
Max. permissible pressure 2.6MPa 2.6MPa
Mains connection 1/N/PE ~220 – 240V / 50Hz 1/N/PE ~220 – 240V / 50Hz
Max. power consumption 0.72 kW 1.06 kW
Nominal current 3.2A 5.4A
Refrigerant R290 R290
Amount of refrigerant 100 g 145 g
GWP factor 3 3
CO
2
equivalent 0.0003 t 0.00044 t
Water tank 3l 6l
Sound pressure level(1m distance) 50 dB(A) 50 dB(A)
Dimensions (lengthx widthx height) 386 x 260 x 500 mm 392 x 282 x 616 mm
Minimum distance to walls or other objects
top (A):
rear (B):
sides (C):
front (D):
40 cm
20 cm
40 cm
20 cm
40 cm
20 cm
40 cm
20 cm
Weight 17 kg 19 kg
