dehumidifier TTK 96 E / TTK 127 E
Spare parts list TTK96E
No. Part Name Quantity No. Part Name Quantity
1 Front Panel Subassembly
1
12.1.2 Left Supporter
1
2 Water Tank Assembly
1
12.1.3 Top Cover
1
2.1 Water Tank Subassembly
1
12.1.4 Rear Panel
1
2.3 Dobber Case
1
12.2 Display Box Subassembly
1
3 Volute Shell Assembly
1
13 Butt Joint Subassembly
1
3.1 Volute Shell
1
14 Drain Connector Of Water Pump
1
3.2 Centrifugal Fan
1
15 Air Filter
1
3.3 Single Phase Asynchronous Motor
1
16 Pipe Temperature Sensor
1
3.4 Supporter Subassembly Of Fan Motor
1
17 Middle Partition Board Assembly
1
4 Capacitor Cap
1
17.1 Partition Board Subassembly
1
5 Capacitor Of Compressor
1
17.2 Micro Switch
1
6 Fixed Speed Rotary Compression
1
18 Electronic Control Box Subassembly
1
7 Suction Pipe Assembly
1
18.1 Electronic Control Box
1
8 Capillary Assembly
1
18.3 Dehumidifier Main Control Board Subassembly
1
9 Evaporator Assembly
1
18.5 Humidity Sensor Board Module
1
10 Condenser Assembly
1
19 Cover Of Electronic Control Box
1
11 Discharge Pipe Assembly
1
20 Chassis Assembly
1
12 Rear Panel Assembly
1
20.1 Chassis Subassembly
1
12.1 Rear Panel Subassembly
1
20.2 Universal Wheel
4
12.1.1 Right Side Plate
1
21 Power Cord Subassembly
1
