Trotec TVE 25 S User Manual

EN 7
pedestal fan TVE 25 S
Mounting and closing the protective grid
1. Fit the front part of the protective grid(16) on the rear part
of the protective grid. Make sure that the two parts are
fixed by the fastening clips(17).
16
17
2. Make sure that the two parts are fixed by all four fastening
clips(17).
17
17
Use the fastening screw(18) at the top of the protective grid to
fasten the two grid parts.
18
Setting the fan's inclination angle
The inclination angle of the fan can be manually adjusted by up
to 30°.
1. Move the fan head forward or back so that it is slightly
inclined either to the front or to the rear. Make sure that
the fan head locks into place at the desired inclination
angle.
ð The fan's inclination angle has been set and the air will
flow out at the selected inclination angle.
