Parts List
Ref. Part No. Description
1 746-04206A Variable Speed Cable
2 731-04150C Rear Baffle 21” Rd.
3 710-04371 Screw 1/4-15
4 731-04204 Deluxe Bail Cover
5 747-1161A Blade Control
6 749-04206 Upper Handle
7 787-01258A Cable Mount Bracket
8 753-05096A Control Lever Assembly
9 720-0279 Handle Knob
10 720-04072 Star Knob
11 710-1205 Eye Bolt
12 746-0957 Control Cable - 37.25”
13 710-1174 Carriage Bolt 5/16-18 x 2.0
14 726-0240 Cable Tie
15 714-0104 Cotter Pin
16 712-0397 Wing Nut
17 664-04011 Grassbag Assembly
18 747-04080 Grass Bag Frame
19 732-0700 Wire
20 731-04998 Trailshield
21 731-04134A Rear Discharge Door
22 750-04162 Spacer
23 732-04089A Torsion Spring - LH
732-04090A Torsion Spring - RH
Ref. Part No. Description
24 747-0996 Pivot Rod
25 731-05020A Transmission Cover (Black)
26 710-1650 Shoulder Screw # 12 -24
27 787-01265A Belt Keeper Bracket
28 749-0928A Lower Handle
29 754-04082A V-Belt
30 756-04161 Upper Pulley Half 25mm x 2.62
31 756-04160 Lower Pulley Half 25mm x 2.62
32 750-04438A Sleeve Spacer 25mm x 1.375 x .62
33 748-04082 Blade Adapter
34 736-0524B Bell Blade Support
35 736-04173 Space Washer
36 736-0250 Flat Washer
37 710-1257 Hex Screw 3/8-24 x 2.50
38 742-0741 21” Mulching Blade
39 731-04177 Side Discharge Chute
40 732-04317 Extension Spring
41 732-04294 Belt Keeper Wire
42 710-04329 Torx Screw
43 710-0896 AB Screw 1/4-14 x .625
44 710-0599 TT Screw 1/4-20 x 0.5
45 710-0703 Carriage Bolt 1/4-20
46 738-1002 Shoulder Screw .375 x .25
