31
REF.
NO.
PART
NO. DESCRIPTION
1 683-0263A Lower Frame Assembly
2 710-0604A Self-tapping Screw, 16-18 x .625
3 783-0726 RH Pivot Support Bracket
4 783-0727 LH Pivot Support Bracket
5 783-0728 Pivot Bar Bracket
6 710-0514 Hex Cap Screw, 3/8-16 x 1 (Grade 5)
7 711-1409 LH Drag Link
8 711-1408 RH Drag Link
9 712-0240 Jam Nut, 7/16-20 (Grade 2)
10 712-0241 Hex Nut, 3/8-24 (Grade 2)
11 712-0431 Flange Lock Nut, 3/8-16
12 712-0459 Flange Lock Nut, 7/16-20
13 712-3004A Flange Lock Nut, 5/16-18
14 717-1550 Steering Gear, 11/90 Ratio
15 717-1554 Steering Pinion Gear
16 723-0448A Ball Joint, 7/16-20
17 736-0169 Lock Washer, 3/8
18 736-3084 Flat Washer, .51 x 1.12 x .06
19 738-1001 Steering Shaft, .625 OD x 24.4
20 741-0475 Plastic Bushing, .38 ID
21 741-0656 Hex Flange Bearing, 5/8
22 748-0416 Shoulder Spacer, .38 ID
23 631-0027 Steering Wheel
24 731-0220 Steering Wheel Cap
25 638-0019 LH Axle Assembly, .625 Diameter
638-0021 LH Axle Assembly, .625 / .750 Diameter
26 638-0020 RH Axle Assembly, .625 Diameter
638-0022 RH Axle Assembly, .625 / .750 Diameter
27 683-0128A Pivot Bar
28 712-0431 Flange Lock Nut, 3/8-16
29 714-0470 Cotter Pin
30 726-0214 Push Cap, 5/8
726-0341 Push Cap, 3/4
31 736-0162 Flat Washer, .64 x 1.0 x .12
32 736-0187 Flat Washer, .64 x 1.24 x .06
736-0316 Flat Washer, .78 x 1.59 x .06
33 736-0285 Flat Washer, .635 x 1.589 x .06
34 738-1011 Shoulder Screw, .5 x 2.2, 3/8-16
35 741-0659 Flange Bearing, .632 ID x .937 OD
741-0660 Flange Bearing, .760 ID x .937 OD
36 634-0105A Wheel Assembly Complete, 15 x 6 x 6
634-0172 Rim Only
734-0255 Air Valve (Not Shown)
734-1731 Tire Only, Square Shoulder
741-0487A Plastic Flange (Not Shown)
741-0706 Plastic Flange w/ Fitting (Not Shown)
37 734-0484A Hub Cap
38 783-0653A Steering Support Bracket
39 738-1020 Shoulder Screw, .625 x .50, 7/16-20
40 736-0331 Bell Washer, .39 x 1.13 x .062
41 738-0140 Shoulder Screw, .435 x .178, 5/16 x .56
42 736-0242 Bell Washer, .34 x .872
43 710-0643 Hex Bolt, 5/16-18 X 1
44 738-0372 Shoulder Spacer, .38 ID
45 731-1291A Pivot Bar End Cap
REF.
NO.
PART
NO. DESCRIPTION
NOTE: For painted parts, please refer to
the list of color codes below. Please add
the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part
numbered 700-xxxx is painted Powder
Black, the part number to order would be
700-xxxx-0637.
MTD Red: 0638
Oyster Gray: 0662
Powder Black: 0637
Steering Assembly
NOTE: Units equipped with a 42-inch deck have axles with a .625 diameter.
Units equipped with a 46-inch deck have axles with a .625 / .750 diameter.
