Troy-Bilt 604 - Page 35

35
REF.
NO.
PART
NO. DESCRIPTION
1 712-0431 FlangeLockNut,3/8-16
2 732-0735 CompressionSpring,1.318x2.37
3 783-0733 SpacerCup,1.5OD
4 732-0956 CompressionSpring,.66ODx1.5
5 710-0604A SelfTappingScrew,5/16-18x.625
6 710-0751 HexCapScrew,1/4-20x.62
7 712-0271 HexSemsNut,1/4-20
8 712-3044 WingNut,1/4-20
9 725-1706 12-voltBattery,270CCA
10 738-1014 ShoulderScrew,.5x1.25,3/8-16
11 738-1020 ShoulderScrew,.625x.5,7/16-20
12 736-0407 BellWasher,.45x1.0x.062
13 723-0444 BatteryStrap
14 783-0668 HitchPlate
15 725-1747 SafetyInterlockPlungerSwitch
16 736-0222 LockWasher,1/4
17 725-1426 Solenoid,12-Volt,100Amp
18 710-0599 SelfTappingScrew,1/4-20x.5
19 712-0459 FlangeLockNut,7/16-20
20 683-0263A LowerFrameAssembly
21 756-0639 EnginePulley,3.56OD
22 711-0640 Stud,3/8-16x2.68
23 712-3010 HexNut,5/16-18
24 710-3180 HexCapScrew,5/16-18x1.75(Grade5)
25 732-0978 ExtensionSpring,1.2ODx3.638
26 714-0118 SquareKey,1/4x1.5
27 736-0277 FlatWasher,1.03x1.62x.095
28 712-3004A FlangeLockNut,5/16-18
29 783-0653A SteeringSupportBracket
30 683-0293 IdlerBracketAssembly(42-inchdecks)
683-0197 IdlerBracketAssembly(46-inchdecks)
31 738-3056 ShoulderScrew,1/2Diameterx2.5
32 717-1708 ElectricPTOClutch
33 738--0785 ShoulderSpacer,1.38x.445x.36
34 736-0171 LockWasher,7/16
35 710-3157 HexCapScrew,7/16-20x3.25(Grade5)
36 710-3011 HexCapScrew,3/8-16x2.25(Grade5)
37 756-0627 FlatIdlerPulley,3.5OD
38 754-0472 PTOBelt(42-inchDecks)
754-0474 PTOBelt(46-inchDecks)
39 783-0349 BatteryTray
40 783-0891 DeckStop
REF.
NO.
PART
NO. DESCRIPTION
NOTE:Forpaintedparts,pleasereferto
thelistofcolorcodesbelow.Pleaseadd
the applicable color code, wherever
needed,tothepartnumbertoordera
replacementpart.Forinstance,ifapart
numbered700-xxxxispaintedPowder
Black,thepartnumbertoorderwouldbe
700-xxxx-0637.
MTDRed:0638
OysterGray:0662
PowderBlack:0637
PowerTake-offSystem
