Servicing the Troy-Bilt Wide Cut 33” Combination Mower
1
TROY-BILT WIDE CUT MOWER
Model 12A-E753B063 (NEW)
• 9 hp briggs & Stratton I/C OHV engine
• Electric Start
• 33” Deck
• Self-Propelled Multiple Speed Gear Drive
• Peerless Transaxle
• BLade Brake Clutch
• Automatic Parking Brake
• Single Lever Height Adjustment
• 3-in-1 Capacity
The Model E753B features a standard size battery and
electric start. See Figure 1.
OLDER STYLE ENGINE
Non Electric Start Unit
Figure 1
Gas Tank
Battery
The key switch is located on the right side of the con-
sole. See Figure 2.
The unit also features an oversize fuel tank with a man-
ual shutoff valve. See Figure 3.
Figure 2
Key Switch
Figure 3
Fuel Shutoff
