Troy-Bilt ProLine - Page 35

Parts List 35
Models 664D, 665B & E666M
1 710-0514 Hex Hd. Screw, 3/8-16 x 1* ................ 16
2 GW-1270-2 Bolo Tine-single. Right hand tine
used on left side of tiller.................. 8
3 712-3000 Hex Locknut, 3/8-16 ........................... 18
5 710-3096 Hex Hd. Screw, 3/8-16 x 2, Grade 8.... 2
7 GW-1270-1 Bolo Tine-single. Left hand tine
used on right side of tiller ............... 8
8 1902154 Tine Holder. For left and right sides .... 2
-- 1901118 Bolo Tine Replacement Set (Incl. eight
ea. right hand and left hand tines,
and sixteen ea. Refs. 1 and 3) ......... 1
-- GW-2475-1 Custom Tilling Bolo Tine, Left hand
tine (see Note 1 above) ................... 8
-- GW-2475-2 Custom Tilling Bolo Tine, Right hand
tine (see Note 1 above) ................... 8
-- GW-10802 Custom Tilling Bolo Tine Replacement
Set (Incl. eight ea. right hand and
left hand custom tines, and sixteen
each of Refs. 1 and 3) ..................... 1
9 GW-9338 Hitch Pin ............................................. 2
10 1917487 Wheel and Tire Assembly ................... 2
11 GW-9380 Clevis Pin, .312 x 1-3/4 ...................... 2
REF. PART
No. No. DESCRIPTION QTY.
REF. PART
No. No. DESCRIPTION QTY.
* Specify GRADE 5 if ordering part locally.
BOLO TINES, WHEELS
IMPORTANT: Left and right sides of
tiller are determined by standing in
operator position and facing direc-
tion of forward travel.
NOTE 1: Custom Tilling Tines are
available for your tiller. These are
special hard-faced tines that are
thicker than standard tines.
