36 Parts List
Bumper – OEM-290-254
1 749-04193 Bumper ............................................ 1
2 777S30653 Decal - Caution.................................. 1
3 710-0395 Screw–hex hd., 5/16-18 x 2-1/4*
(included in hardware kit) ........... 4
4 736-0119 Lockwasher–5/16*
(included in hardware kit) ............. 4
5 712-04063 Lock Nut–Hex, Nylon, 5/16-18*
(included in hardware kit) ............. 4
--- 1918781 Hardware Kit: Incl. four each of
Refs. 3, 4 and 5 ............................. 1
REF PART
No. No. DESCRIPTION QTY.
REF PART
No. No. DESCRIPTION QTY.
Models 664D, 665B & E666M
BUMPER ATTACHMENT
1
2
5
4
3
BUMPER
OEM-290-254
