Troy-Bilt ProLine - Page 37

Parts List 37
Models 664D, 665B & E666M
HOOD, BRACKET and DEPTH REGULATOR
1 686-04013 Tine Hood ........................................... 1
2 710-0169 Lockwasher, 3/8.................................. 2
3 GW-2525 Bracket–hood & depth regulator ......... 1
4 710-04049 Hex Flange Screw, 5/16-18 x 5/8* ...... 2
5 712-0291 Hex Locknut, 1/4-20 ........................... 1
6 710-0597 Hex Hd. Screw, 1/4-20 x 1* ................ 1
7 GW-9384 Spring ................................................. 1
8 GW-9534 Spacer................................................. 1
9 1185469 Roll Pin (spiral), 1/4 x 1 ..................... 1
10 GW-1117A Depth Adjustment Bar Assembly
(Incl. Refs. 11 and 12) .................... 1
11 GW-9120 Retaining Ring (tolerance ring) ........... 1
12 GW-9119 Knob, Depth Regulator (Incl. Ref. 11). 1
13 710-3005 Hex Hd. Screw, 3/8-16 x 1-1/4*.......... 2
14 GW-1113-1 Bushing, Drag Bar............................... 2
15 712-3017 Hex Nut, 3/8-16................................... 2
16 GW-20775 Drag Bar ............................................. 1
17 777S30649 Decal, operating instructions .............. 1
18 710-0759 Hex Hd. Screw, self-tapping,
5/16-18 x 5/8* ................................ 2
19 710-0599 Hex Flange Screw, self-tapping,
1/4-20 x 1/2* .................................. 2
REF. PART
No. No. DESCRIPTION QTY.
REF. PART
No. No. DESCRIPTION QTY.
* Specify GRADE 5 if ordering part locally.
Transmission
618-04002
