Safety • Assembly • Operation • Adjustments • Maintenance • Troubleshooting • Parts Lists • Warranty
P. O. Box 1386, KITCHENER, ONTARIO N2G 4J1
PRINTED IN U.S.A.
IMPORTANT:
READ SAFETY RULES AND
INSTRUCTIONS CAREFULLY
BEFORE OPERATION
OPERATOR’S MANUAL
Two-Stage Snow Thrower
www.troybilt.ca
769-05189
6/24/09

Table of Contents

Questions and Answers

  • L
    Luis PerryJul 31, 2025
    Why Troy-Bilt Snow Thrower Snow Blower engine runs erratic?
    • Z
      Zachary CarpenterJul 31, 2025
      If your Troy-Bilt Snow Blower engine runs erratically, it could be due to several reasons: * The unit might be running on CHOKE. Move the choke lever to the OFF position. * The fuel line could be blocked, or the fuel could be stale. Clean the fuel line and fill the tank with fresh gasoline. * There might be water or dirt in the fuel system. Drain the fuel tank and refill it with fresh fuel.
  • A
    Allison BatesAug 5, 2025
    What to do if Troy-Bilt Snow Blower fails to discharge snow?
    • D
      Derrick WhiteAug 6, 2025
      If your Troy-Bilt Snow Blower isn't discharging snow, here's what might be happening: * The chute assembly could be clogged. Stop the engine immediately, disconnect the spark plug wire, and clean the chute assembly and the inside of the auger housing with a clean-out tool or stick. * A foreign object might be lodged in the auger. Stop the engine immediately, disconnect the spark plug wire, and remove the object from the auger with a clean-out tool or stick. * Shear pins may be sheared. Replace them with new shear pins.
  • L
    Lee WarrenAug 10, 2025
    Why Troy-Bilt Snow Thrower Snow Blower has loss of power?
    • N
      Nathan RamosAug 10, 2025
      If your Troy-Bilt Snow Blower is losing power, consider these potential issues: * The spark plug wire might be loose. Connect and tighten the spark plug wire. * The gas cap vent could be plugged. Remove any ice and snow from the gas cap to ensure the vent is clear.
  • D
    Dylan RodriguezAug 16, 2025
    What to do if Troy-Bilt Snow Thrower Snow Blower unit fails to propel itself?
    • C
      Christian RossAug 16, 2025
      If your Troy-Bilt Snow Blower isn't moving on its own, possible causes include: * The drive belt might be loose or damaged. Replace the drive belt. * The friction wheel could be worn. Replace the friction wheel.
  • D
    Diana NicholsonAug 20, 2025
    How to fix excessive vibration in Troy-Bilt Snow Thrower Snow Blower?
    • S
      Scott Murphy MDAug 20, 2025
      If your Troy-Bilt Snow Blower is vibrating excessively, it could be due to loose parts or a damaged auger. Immediately stop the engine and disconnect the spark plug wire. Tighten all bolts and nuts. If the vibration continues, the unit should be serviced by a Service Center.
  • A
    Angel SotoOct 25, 2025
    Why Troy-Bilt Snow Blower engine fails to start?
    • D
      Darrell OsbornOct 25, 2025
      If your Troy-Bilt Snow Blower's engine won't start, possible causes include: * The choke might not be in the ON position. Solution: Move the choke to the ON position. * The spark plug wire could be disconnected. Solution: Connect the wire to the spark plug. * The fuel tank may be empty or contain stale fuel. Solution: Fill the tank with clean, fresh gasoline. * The engine might not have been primed. Solution: Prime the engine as instructed in the manual. * The spark plug could be faulty. Solution: Clean, adjust the gap, or replace the spark plug. * The fuel line could be blocked. Solution: Clean the fuel line. * The safety key might not be fully inserted. Solution: Insert the key fully into the switch. * The fuel shut-off valve might be closed (if equipped). Solution: Open...

Summary

1 Safety Symbols and Warnings

Safety Symbol Descriptions and Warnings

Explains safety symbols and general warnings for safe operation of the snow thrower.

2 Safe Operation Practices

Operator Training and Area Preparation

Safe Gasoline Handling Procedures

General Operation Safety Rules

Outlines safe practices during snow thrower operation.

Continued Safe Operation Practices

Clearing Clogged Discharge Chutes Safely

Instructions on safely clearing a clogged discharge chute.

3 Setting Up Your Snow Thrower

Handle and Chute Assembly Instructions

Chute Control Rod Installation Procedure

4 Operating Your Snow Thrower

Understanding Snow Thrower Controls and Features

Identification and function of main controls and engine parts.

Engine Starting and Control Operations

Explanation of choke, primer, ignition, and throttle controls.

Engaging Auger and Drive Systems

How to engage augers, drive, steering, and use heated handles.

Chute Operation and Clean-Out Tool Usage

Starting and Stopping the Engine

Starting Non-Electric Engines Guide

Procedure for starting engines with a pull starter.

Starting Electric Engines Guide

Procedure for starting engines using an electric starter.

Safe Engine Shutdown Procedures

Safe procedures for shutting down the engine after use.

Operational Procedures

Engaging Drive and Augers for Operation

Auger Control Safety Test Procedure

5 Making Adjustments

Shift Cable and Chute Control Rod Adjustment

Drive Control Cable Adjustment Procedure

6 Maintaining Your Snow Thrower

Engine and Gear Lubrication and Care

Wheel and Auger Shaft Maintenance

Auger, Shave Plate, and Skid Shoe Care

7 Troubleshooting Common Issues

Engine and Drive System Problems and Solutions

Auger, Vibration, and Discharge Problems

Troy-Bilt Snow Thrower Specifications

General IconGeneral
Intake Height21 inches
Auger MaterialSteel
Self-PropelledYes
Electric StartYes
Throw Distance40 feet
