TROY-BILT LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019

Printed In USA

Op e r a t O r ’s Ma n u a l

Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty

WARNING

READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL

BEFORE ATTEMPTING TO OPERATE THIS MACHINE.

FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.

Two-Stage Snow Thrower — Storm 2410

Form No. 769-04037

(April 25, 2008)

Questions and Answers

G
Gerald LoganSep 12, 2025
What to do if my Troy-Bilt Snow Blower won't throw snow?
- M
  Melissa MillerSep 12, 2025
  If your Troy-Bilt snow blower isn't discharging snow, here's what to check: 1. Immediately stop the engine and disconnect the spark plug wire before inspecting or performing maintenance. 2. The chute assembly might be clogged; clean it and the inside of the auger housing with a clean-out tool or stick. 3. A foreign object could be lodged in the auger; remove it with a clean-out tool or stick. 4. Also, check the shear pins and replace them if they are sheared. For other issues, refer to the Auger Control Test or the Maintenance & Adjustments section for the auger belt.
S
Shannon BryantAug 25, 2025
Why is my Troy-Bilt Snow Blower not moving?
- A
  Aaron ReyesAug 25, 2025
  If your Troy-Bilt snow blower isn't propelling itself, the drive control cable may need adjustment; refer to the Maintenance & Adjustments section. Alternatively, the drive belt might be loose or damaged, or the friction wheel could be worn; in either case, refer to the Service section for replacement.
J
Joel TaylorAug 26, 2025
What to do if my Troy-Bilt Storm 2410 Snow Blower doesn't discharge snow?
- C
  Courtney WilsonAug 26, 2025
  If your Troy-Bilt Snow Blower unit fails to discharge snow, consider the following: * The chute assembly might be clogged. Stop the engine immediately, disconnect the spark plug wire, and clean the chute assembly and inside of the auger housing with a clean-out tool or a stick. * A foreign object could be lodged in the auger. Stop the engine immediately, disconnect the spark plug wire, and remove the object from the auger using a clean-out tool or a stick. * The shear pins might be sheared. Replace them with new shear pins.
A
ashley09Aug 27, 2025
Why does my Troy-Bilt Snow Blower engine run erratic?
- O
  ortegajohnnyAug 27, 2025
  If the engine of your Troy-Bilt Snow Blower runs erratically, here are a few potential reasons: * The engine may be running on CHOKE. Move the choke lever to the OFF position. * You might be using stale fuel. Fill the tank with clean, fresh gasoline. * There could be water or dirt in the fuel system. Drain the fuel tank and refill it with fresh fuel.
K
Kimberly BrooksAug 29, 2025
How to fix loss of power in my Troy-Bilt Snow Blower?
- N
  navarrocharlesAug 29, 2025
  If your Troy-Bilt Snow Blower experiences a loss of power, check these items: * Ensure the spark plug wire is securely connected and tightened. * Check the gas cap vent hole for blockage. Remove any ice and snow, and ensure the vent hole is clear.
A
Amber AndersonAug 31, 2025
Why my Troy-Bilt Storm 2410 Snow Blower engine running erratically?
- M
  mperryAug 31, 2025
  An erratic engine in your Troy-Bilt Snow Blower, characterized by inconsistent RPM (hunting or surging), can stem from several causes. It might be running on CHOKE, in which case you should move the choke lever to the RUN position. Stale fuel could also be the culprit; try filling the tank with clean, fresh gasoline. Another possibility is water or dirt in the fuel system, requiring you to drain the fuel tank and refill it with fresh fuel. In some cases, the carburetor may be out of adjustment or the engine may be over-governed, both of which necessitate contacting an authorized Service Center.
M
Matthew BondNov 21, 2025
Why Troy-Bilt Snow Blower engine fails to start?
- K
  Kenneth WilliamsNov 22, 2025
  Your Troy-Bilt Snow Blower engine may fail to start due to several reasons: * The choke might not be in the CHOKE position, so move the choke to the CHOKE position. * The spark plug wire might be disconnected, so connect the wire to the spark plug. * The fuel tank might be empty or contain stale fuel, so fill the tank with clean, fresh gasoline. * The engine might not be primed, so prime the engine as instructed in the Operation section. * The spark plug might be faulty, so clean, adjust the gap, or replace it. * The key might not be in the ignition, so insert the key fully into the switch. * The extension cord might not be connected (when using the electric start button), so connect one end of the extension cord to the electric starter outlet and the other end to a three-p...
J
Jason CampbellSep 13, 2025
Why does my Troy-Bilt Snow Blower lose power?
- R
  Richard MoodySep 13, 2025
  Loss of power in your Troy-Bilt snow blower can occur if the spark plug wire is loose; connect and tighten it. Another possible cause is a plugged gas cap vent hole; remove any ice or snow and ensure the vent hole is clear.
J
John WheelerSep 10, 2025
Why is my Troy-Bilt Snow Blower engine running erratically?
- W
  William CampbellSep 10, 2025
  An erratic engine in your Troy-Bilt Snow Blower could be due to several reasons: * The engine might be running on CHOKE – move the choke lever to the RUN position. * Stale fuel could be the culprit – replace it with clean, fresh gasoline. * There might be water or dirt in the fuel system – drain the tank and refill with fresh fuel. * If these steps don't work, the carburetor may be out of adjustment or the engine over-governed, and you should contact an authorized Service Center.
M
michael80Sep 6, 2025
What to do if Troy-Bilt Snow Blower unit fails to propel itself?
- S
  Sydney JamesSep 7, 2025
  If your Troy-Bilt Snow Blower unit fails to propel itself, the drive control cable may need adjustment; refer to the Maintenance & Adjustments section to adjust it. Alternatively, the drive belt may be loose or damaged, or the friction wheel may be worn, in which case you should contact an authorized Service Center.

Summary

Owner Information and Support

Record Product Information

Record serial and model numbers for future technical support needs.

Customer Support Contact

How to contact Troy-Bilt for assistance with assembly, operation, or maintenance.

Important Safe Operation Practices

Safety Warnings and Precautions

Key warnings about hazards, chemicals, and safety symbols for safe operation.

Operator Training and Preparation

Instructions for operator training and preparing the area before use.

Safe Handling of Gasoline

Operation Guidelines

Basic Operation Controls

Using controls like auger, drive, shift levers, and chute assembly safely.

Safe Operating Environment

Ensuring safe operation regarding location, bystanders, visibility, and terrain.

Operational Hazards and Precautions

Addressing vibration, unclogging, attachments, starting, and general prudence.

Maintenance and Storage

Routine Maintenance and Checks

Regular checks of safety devices, bolts, controls, labels, and proper disposal.

Storage Procedures

Steps for preparing the machine for off-season storage.

Engine Maintenance and Warnings

Warnings on engine modification, emissions, and spark arrestor requirements.

Summary

Owner Information and Support

Record Product Information

Record serial and model numbers for future technical support needs.

Customer Support Contact

How to contact Troy-Bilt for assistance with assembly, operation, or maintenance.

Important Safe Operation Practices

Safety Warnings and Precautions

Key warnings about hazards, chemicals, and safety symbols for safe operation.

Operator Training and Preparation

Instructions for operator training and preparing the area before use.

Safe Handling of Gasoline

Operation Guidelines

Basic Operation Controls

Using controls like auger, drive, shift levers, and chute assembly safely.

Safe Operating Environment

Ensuring safe operation regarding location, bystanders, visibility, and terrain.

Operational Hazards and Precautions

Addressing vibration, unclogging, attachments, starting, and general prudence.

Maintenance and Storage

Routine Maintenance and Checks

Regular checks of safety devices, bolts, controls, labels, and proper disposal.

Storage Procedures

Steps for preparing the machine for off-season storage.

Engine Maintenance and Warnings

Warnings on engine modification, emissions, and spark arrestor requirements.

Troy-Bilt Storm 2410 Specifications

General

Engine Type	4-Cycle
Engine Displacement	208cc
Clearing Width	24 inches
Intake Height	21 inches
Chute Control	Manual
Speeds	6 Forward / 2 Reverse
Fuel Capacity	2 quarts
Chute Rotation	180 degrees
Auger Material	Steel
Skid Shoes	Adjustable
Start Type	Recoil and Electric
Throw Distance	Up to 30 feet
Wheels	13 in x 4 in
