S18
PARTS LIST
Item Part
No. Description
1 753-05363 Engine Cover Assembly (includes 2 & 51)
2 753-04595 Cover Screw
3 791-181003 Screw
4 753-05209 Rocker Cover
5 753-05210 Rocker Cover O-Ring
6 753-05228 Cylinder Assembly (includes 3, 5 & 9)
7 753-05229 Piston Ring Assembly
8 753-05230 Piston Assembly (includes 7)
9 753-05232 Cylinder O-Ring
10 791-182379 Breather Hose
11 753-05236 Oil Plug (includes 12)
12 791-182290 Oil Plug O-Ring
13 753-05237 Crankcase Cover
14 753-05238 Crankcase Cover O-ring
15 753-05364 Crankcase Assembly (includes 9, 10 & 14)
16 753-05240 Flywheel Assembly
17 753-05241 Cam Bracket Assembly (includes 18)
18 753-05242 Cam Bracket Screw
19 753-05365 Lead Wires
20 753-05243 Module Assembly
21 753-05244 Muffler Gasket
22 753-05245 Muffler Assembly (includes 21 & 23)
23 753-05246 Muffler Screw
24 753-05255 Spark Plug
25 753-05247 Insulator Gasket
26 753-05248 Nut
27 753-05249 Insulator (includes 28)
28 753-05366 Carburetor Gasket
29 753-05367 Carburetor w/Primer
Item Part
No. Description
30 791-181751 O-Ring
31 753-05368 Throttle Lever Assembly
32 753-05302 Air Cleaner Cover Assembly (includes 33)
33 753-05254 Air Filter
34 753-05253 Screw
35 753-05256 Fuel Tank Assembly w/Fuel Lines (includes 36)
36 753-1229 Fuel Cap
37 753-05259 Fuel Tank Pads
38 753-05260 Push Nut
39 753-1202 Pressure Plate Screw
40 753-05074 Pressure Plate (includes 39)
41 753-05369 Spacer
42 753-05386 Starter Assembly (includes 43)
43 791-182661 Rope
44 753-04286 Recoil Spring
45 753-05387 Starter Housing Assembly (includes 38-42 & 51)
46 753-04809 Mounting Plate Assembly (includes 47 & 48)
47 791-182409 Washer
48 753-04755 Screw
49 791-182396 Washer
50 791-181524 Nut
51 753-05377 Screw
52 753-05512 Air Cleaner Gasket
* 753-05297 Spark Arrestor Assembly
* 753-05371 Shortblock Assembly
(includes 3-12, 14, 15, 17, 24 & 51)
* Parts Not Shown
REPLACEMENT PARTS - MODEL TB360BV
4-CYCLE GAS BLOWER
