5
CAUSE ACTION
Cutting attachment bound with grass Stop the engine and clean cutting attachment
Cutting attachment out of line Refill with new line
Inner reel bound up Replace the inner reel
Cutting head dirty Clean inner reel and outer spool
Line welded
Disassemble, remove the welded section and
rewind
Line twisted when refilled Disassemble and rewind the line
CHARGER MAINTENANCE
• Keep the charger clean and clear of debris. Do not allow foreign material into the recessed cavity or
on the contacts.
• Wipe with a dry cloth. Do not use solvents, water or place in wet conditions.
• Always unplug the charger when not in use.
• The battery Pack may be stored in the charger. However, it is recommended to disconnect the
charger from the power source.
• To ensure safety and reliability, all repairs should be performed by a qualified service technician.
• Check that the charger contacts have not been shorted by debris or foreign material.
• Keep the charger and battery pack in an area that is between 65 and 75˚ F (18 and 24˚ C).
CLEANING
1. Wipe the outside of the unit with a dry, soft cloth. Do not hose down or wash with water.
2. Scrape the guard and spool area to remove dried clippings and mud.
3. Brush or blow dust, debris and grass clippings out of the air vents. Keep them free or obstructions
STORAGE
• Lock up the unit to prevent unauthorized use or damage.
• Store the unit in a dry, well-ventilated area.
• Store the unit out of the reach of children.
ENVIRONMENTALLY SAFE BATTERY DISPOSAL
To avoid damage to the environment:
• Cover the battery terminals with heavy-duty adhesive tape.
• DO NOT attempt to remove or destroy any of the battery pack components.
• DO NOT attempt to open the battery pack.
• DO NOT place the battery pack in the regular household trash.
• DO NOT incinerate.
• DO NOT place them where they will become part of any waste landfill or municipal solid waste
stream.
• If a leak develops, the released electrolytes are corrosive and toxic. DO NOT get the solution in your
eyes or on your skin, and do not swallow it.
• Dispose of the battery pack in accordance with local state and federal regulations.
MAINTENANCE AND REPAIR INSTRUCTIONS
WARNING:
To avoid risk of fire, electric shock or electrocution:
• Do not use a damp cloth or detergent on the battery or battery charger.
• Always remove the battery pack prior to cleaning, inspecting or performing any
maintenance on the unit
The following toxic and corrosive materials are used in this units battery pack:
LITHIUM-ION, a toxic material.
WARNING:
All toxic materials must be disposed of in a specified manner to prevent
contamination of the environment. Before disposing of damaged or worn out lithium-ion
battery packs, contact your local waste disposal agency for information and specific
instructions. Take batteries to a local recycling and or disposal center, certified for lithium-ion
battery disposal.
WARNING:
Do not use the battery pack if there are cracks or if it breaks, regardless if
there is leakage or not. Replace with a new battery pack. DO NOT ATTEMPT TO REPAIR! As
this may cause severe personal injury due to explosion or electrical shock.
TROUBLESHOOTING
BATTERY AND MOTOR
Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24V 6Ah
Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Lithium-Ion, 20 Volt
Motor Wire Housing Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Aluminum Tube
Unit Weight (With battery, cutting attachment shield and D-handle) . . . . . . . . . . . . . . . . 8.2 lbs. (3.86 kg.)
Cutting Mechanism. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Auto Feed
Trimming Line Diameter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.065 in (1.65 mm.)
Cutting Path Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 in. (30.5 cm)
SPECIFICATIONS
CAUSE ACTION
Cutting head is broken Replace as needed
CAUSE ACTION
No power to charger or battery Check charger and charging station
Battery has failed Replace the battery
CAUSE ACTION
Battery is not charged Charge the battery
CUTTING HEAD WILL NOT ADVANCE LINE
CUTTING HEAD ADVANCES LINE UNCONTROLLABLY
MOTOR OPERATES SLOWLY OR WILL NOT OPERATE
BATTERY WILL NOT CHARGE
