Please find 4 feet in the packaging, you can screw them into the bottom of the unit,
thenthe unit can be used directly on the countertop.
5
I. Cooktop Installation Continued...
USE---- COUNTERTOP
•
•
•
First feed the power wire through the hole and to the location of the power receptacle un-
derneath the cabinet.
The 'h'' overhang on the induction cooker comes with pre-installed foam gasket. Peel off the
adhesive protector on the bottom of the gasket and set the induction cooker into the cut-
out. Gently press down on the induction cook top to secure the adhesive gasket to the coun-
tertop. The cook top should be sitting on the supports previously installed.
Fo
r R
V use, apply butyl tape instead of the supplied foam tape. Butyl tape will provide ade-
quate adhesion and still allow for removal if the unit needs to be serviced.
P.2
DOUBLE BURNER MD-2B INDUCTION COOKTOP MANUAL
take out screw
before installing
Parts
