True CS800 Troubleshooting Guide

1. Disconnect the console cable from the upper console.
2. Check for 12 VDC on pins 1 (+12V), and 4 (GND), and check for
12 VDC on pins 2 (+12V), and 4 (GND). 11 &12= 12v, 9 & 10=
gnd
3. If 12 VDC is found across both pins, replace the upper console.
4. If 12 VDC is not found, check for continuity on the console cable.
5. If there is no continuity, replace the console cable.
6. If there is continuity on the console cable, locate the VCON LED
and GEN+ LED on controller.
7. If GEN+ LED is illuminated when pedaling and the VCON LED is
not lit, replace the controller.
8. If GEN + LED is not illuminated, check for Volts AC from the
generator cable (black and white wires) connected to J1 on the
controller. The reading should be approximately 50-80 Volts AC
at slow speed.
10
No Power/Console
Display Not
Powering Up 2
Window Display
CS800/LC900 Bike
