INSTALLATION / OPERATION INSTRUCTIONS
Final Location
A. Placestyrofoamcornersbehindcoolerforcushion
andcarefullytiltunitonit’sback.
B. Removethelouveredgrillbyremovingfourphillips-
headscrews.
C. Removethefourboltsfromtheskidwithan
adjustablewrench,andlocatethefourcastors.
Castorsareplacedinsidecooler,withinthebubble
wrap.
D. Installonecastorineachofthefourfemalethreaded
areasasindicated.
NOTE
Two out of the four castors are designated with an “F” for
front. These are provided with hand-brakes. Position these
castors in FRONT of the unit.
E. Whenallcastorshavebeenthreadedfully,replace
grillandliftunit;positioningitintoitsfinallocation.
F. Ensurethatthetwofrontcastorsarepositioned
FORWARDasillustratedandlockeddownwiththe
hand-brakes.
WARNING
Unit may tip forward if procedure “F” is not
strictly followed.
G. Unitsfinallocationshouldbeadequatelyventilated.
Conditionswhereheatexceeds100ºFrequirean
exhaustfan.
H. Ensurethatthedrainhoseforhosesarepositionedin
thepan.
I. Freeplugandcordfrominsidethelowerrearofthe
cooler(DoNotPlugIn.)
WARNING
Warranty is VOID if ventilation is insufficient.
J. Theunitshouldbeplacedcloseenoughtothe
electricalsupplysothatextensioncordsareNEVER
used.
WARNING
Cabinet warranties are void if OEM power cord is tampered
with. TRUE will not warranty any units that are connected to
an extension cord.
K. ProperlevelingofyourTRUEcooleriscriticalto
operatingsuccess.Effectivecondensateremovaland
dooroperationwillbeeffectedbyleveling.Adjust
castorsoraddshims.
INSTALLING OPTIONAL CASTORS ON GDM-10
AND GDM-12 MODELS
POSITIONING OF THE
CASTOR IS CRITICAL.
ORIENT THE CASTOR IN
THE FORWARD POSITION
AS SHOWN
