CHAPTER 2: ASSEMBLY INSTRUCTIONS
Truefitness.com / 800.426.6570 / 636.272.7100 11
ASSEMBLY STEPS (continued):
STEP 5 Attach Seat Latch Bar & Seat Handlebar:
a) Use two screws to attach the seat adjustment
handle to the seat carriage.
Hardware Required:
#28 - Screw M5x20mm
b) Connect the heart rate wires coming from
the handlebar to the corresponding wires
coming from the bike frame.
c) Use 4 screws to connect the handlebar to the
seat carriage.
Hardware Required:
#208 - Screw M8x1.25x15mm
STEP 6 Seat Assembly:
a
) Mount the seat bottom cushion with 4
screws, 4 lock washers and 4 flat washers.
Hardware Required:
#131 - Screw M6x15mm Sock Hd
#132 - Lock Washer M6
#133 - Flat Washer M6x16x1.12mm
