INSTALLATION / OPERATION INSTRUCTIONS
PIZZA PREP TABLES
A. Removereargrillandthreadelectriccordthrough
grommetingrill.
B. Replacegrill.
C. AligncuttingboardwithRivnutsandattachretainer
cliptotabletop(figure1).
D. Installthelidbrackets.Notethatthereisa
specificallydesignedleft,center(ifapplicable),and
rightbracket.
CUTTING BOARD
RETAINER
CLIP
TABLE TOP
Figure 1.
ANCHORING THE TSSU HOOD COVER
TSSU Hood Installation Instruction
A. RemovereargrillandthreadelectriccordThisis
TRUE’srecommendedprocedureforinstallingthe
fastenersrequiredtoconnectthesandwichsalad
hoodcovertothehood.
 Seecallout#1ontheillustration.
Assembly
1.Locatethehoodcover,(packagedwithinthecard-
boardcontainerontopofthesaladsandwichunit),
andpositionunderthehood.
2.Removetheslottedthumbscrewfromhoodbyback-
ingoutthefactoryinstalled,slottedthumbscrew.
Seediagramofslottedscrewandcallout#2.
3.Placehoodcoverintofinalposition,(beneathhood),
alignhoodhingepinwithanchorholeonhoodcover
andre-attachfastenerbyreplacingthumbscrewinto
hingepin.
4.Repeatprocedureforbothendsofhood.
1
2
HOOD
HOOD COVER
FASTENER
ASSEMBLY
HINGE PIN
