True TRCB-48 - Wire Gauge Chart; Wire Advisement

Chef Base Series
TEC_TM_159 | REV. A | EN 07/6/2022 Page 5 of 19
www.truemfg.com
Cooking Equipment Weight Limits
Chef Base cabinet tops are designed to support countertop
cooking equipment. See cooking equipment weight limits in the
table below.
• Install countertop cooking equipment with their manufacturer-
supplied legs.
• Minimum 4" (101.6 mm) clearance between TRCB's top and the
bottoms of cooking equipment heating elements. Failure to
provide clearance voids manufacturer warranty.
• For optimum performance, TRUE recommends installing a heat
shield (not supplied by TRUE).
115
Volts Distance In Feet To Center of Load
AMPS 20' 30' 40' 50' 60' 70' 80' 90' 100' 120' 140' 160'
2 14 14 14 14 14 14 14 14 14 14 14 14
3 14 14 14 14 14 14 14 14 14 14 14 12
4 14 14 14 14 14 14 14 14 14 12 12 12
5 14 14 14 14 14 14 14 12 12 12 10 10
6 14 14 14 14 14 14 12 12 12 10 10 10
7 14 14 14 14 14 12 12 12 10 10 10 8
8 14 14 14 14 12 12 12 10 10 10 8 8
9 14 14 14 12 12 12 10 10 10 8 8 8
10 14 14 14 12 12 10 10 10 10 8 8 8
12 14 14 12 12 10 10 10 8 8 8 8 6
14 14 14 12 10 10 10 8 8 8 6 6 6
16 14 12 12 10 10 8 8 8 8 6 6 6
18 14 12 10 10 8 8 8 8 8 8 8 5
20 14 12 10 10 8 8 8 6 6 6 5 5
25 12 10 10 8 8 6 6 6 6 5 4 4
30 12 10 8 8 6 6 6 6 5 4 4 3
35 10 10 8 6 6 6 5 5 4 4 3 2
40 10 8 8 6 6 5 5 4 4 3 2 2
45 10 8 6 6 6 5 4 4 3 3 2 1
50 10 8 6 6 5 4 4 3 3 2 1 1
230
Volts Distance In Feet To Center of Load
AMPS 20' 30' 40' 50' 60' 70' 80' 90' 100' 120' 140' 160'
5 14 14 14 14 14 14 14 14 14 14 14 14
6 14 14 14 14 14 14 14 14 14 14 14 12
7 14 14 14 14 14 14 14 14 14 14 12 12
8 14 14 14 14 14 14 14 14 14 12 12 12
9 14 14 14 14 14 14 14 14 12 12 12 10
10 14 14 14 14 14 14 14 12 12 12 10 10
12 14 14 14 14 14 14 12 12 12 10 10 10
14 14 14 14 14 14 12 12 12 10 10 10 8
16 14 14 14 14 12 12 12 10 10 10 8 8
18 14 14 14 12 12 12 10 10 10 8 8 8
20 14 14 14 12 10 10 10 10 10 8 8 8
25 14 14 12 12 10 10 10 10 8 8 6 6
30 14 12 12 10 10 10 8 8 8 6 6 6
35 14 12 10 10 10 8 8 8 8 6 6 5
40 14 12 10 10 8 8 8 6 6 6 5 5
50 12 10 10 8 6 6 6 6 6 5 4 4
60 12 10 8 6 6 6 6 6 5 4 4 3
70 10 10 8 6 6 6 5 5 4 4 2 2
80 10 8 8 6 6 5 5 4 4 3 2 2
90 10 8 6 6 5 5 4 4 3 3 1 1
100 10 8 6 6 5 4 4 3 3 2 1 1
Wire Gauge Chart
Cooking Equipment Weight Limits
MODEL MAXIMUM WEIGHT
TRCB-36/48/52/52-60 717 lb (326 kg)
TRCB-72/79/79-86/82/82-84/82-86 1084 lb (492 kg)
TRCB-96 1434 lb (651 kg)
TRCB -110 2000 lb (908 kg)
