Cabinet Setup
Drawer Removal and Installation #1
Removal
1. Completely open the drawer.
2. Locate the roller clips (in down position; see figs. 1 and 2).
3. While holding the sides of the drawer, rotate the roller clips
upward. See fig. 3.
4. Lift the drawer from the channel slot.
Installation
1. With the roller clips in the up position (see fig. 3), lower the
drawer’s rear rollers into the channel slots.
2. Push the drawer into position.
3. Rotate the roller clips to the down position. See figs. 1 and 2.
Fig. 1. Roller clip location.
Fig. 2. Roller clip in down position.
Fig. 3. Rotate the roller clip upward.
Fig. 4. Carefully lift the drawer from the channel slots.
