Truma MonoControl CS User Manual

11EN
The test must be conducted by a technician
The gas hose and gas cylinder must be connected.
– Turn off all consumers.
– Open stop valves and, if present, the gas remote switch.
– Press in the triggering element of the crash sensor (9) sufficiently
far that the yellow reset button(7) comes out so that the crash sen-
sor is in the “not ready for operation” position (figure 2b).
– Remove the screw cap (10) from the test connection and connect
the test pump with test hose to the test connection.
10
7
9
Figure 3: MonoControl CS
– Check for leaks (e.g in Germany in accordance with G 607).

Truma MonoControl CS Specifications

General

Category	Controller
Safety feature	Crash sensor
Operating pressure	30 mbar
Regulator capacity	1.5 kg/h
Type	Gas pressure regulator
Gas type	Propane/butane
Inlet pressure	0.3 to 16 bar
Installation	Vertical
Power Supply	Not applicable
Display	No
